SupplyLuzhou JG02P-SY400 rotary table diameter gauge
Key words: Rotary table diameter gauge, workpiece diameter gauge, workpiece outer diameter inspection, cylindrical workpiece diameter measurement
Product Introduction
The equipment uses adjustable measurement range dual probes to measure the diameter dimensions of the upper and lower cross-sections of cylindrical objects. The equipment is equipped with a rotatable stage. Place the object to be measured on the stage. After starting the measurement, the stage will rotate once and the measurement will automatically end.
During the measurement process, the software system displays real-time measurement data, and at the same time, the system automatically statistically calculates the maximum value, minimum value, erage value, ellipticity, integral perimeter and other statistical data of the measurement data. After the measurement is completed, the software interface displays the maximum value, minimum value, erage value and ellipticity of the diameter data. When switched to the perimeter mode, the maximum value, minimum value and erage value of the perimeter are displayed.
The equipment is mainly used for batch inspection of cylindrical processed parts, honeycomb ceramic carriers and other parts.
Product features
(1) Maximum, minimum and erage diameter alarm functions
(2) erage diameter grading alarm function
(3) Maximum, minimum and erage perimeter alarm functions
(4) erage perimeter classification alarm function
(5) Data Storage: Measurement data is automatically recorded and stored for more than one year. The dimensions of a certain measured part can be queried
(6) Data export function: Data can be exported in Excel format and transmitted to other computers via a local area network
(7) Product parameter Settings: Parameters such as the nominal diameter, height, and grading tolerance of the product can be set
(8) System parameter Settings: Fault channels, communication ports, system zero calibration, etc. can be set
(9) Probe spacing adjustment function: When switching product specifications, the probe spacing and the height of the upper probe will be automatically adjusted. After inputting the adjustment dimensions, the probe spacing and the height of the upper probe will be adjusted
(10) Correction function: After placing the standard gauge block and inputting the standard diameter for calibration, measurement errors can be eliminated
Technical parameters
Measurement range () : Φ50 to Φ400;
2. Measurement accuracy () : ≤±0.02;
3. Two-layer probe measurement distance () : 35-200;
4. Repeatability accuracy () : < ±0.01;
5. Measuring frequency (Hz) : 2000;
6. Rotating tray speed (r/min) : Adjustable from 5 to 10.
